Introduction to Plumbing Pipe Materials

Podcast Beta

Play an AI-generated podcast conversation about this lesson

Questions and Answers

What temperature is used to heat the clay pipe in the kiln?

1500 °C

800 °C

1000 °C

1370 °C (correct)

Why is lead pipe not used for conveying water for human consumption?

It is poisonous and injurious to human health. (correct)

It deteriorates quickly in hot water.

It is highly resistant to corrosion.

It is too expensive for plumbing.

Which pipe is known to deteriorate faster when used as a hot water supply line?

Clay pipe

Brass pipe

Galvanized steel pipe (correct)

Lead pipe

What is a key characteristic of clay pipes?

They are highly resistant to acid wastes. Signup and view all the answers

Which of the following statements is accurate regarding galvanized steel pipes?

They are subject to corrosion from acidic water. Signup and view all the answers

In terms of plumbing quality, how does galvanized wrought iron pipe compare to steel pipe?

It is better in quality. Signup and view all the answers

What are the components of the alloy used to make brass pipes?

15% zinc and 85% copper Signup and view all the answers

What is a physical property of clay pipes?

They are brittle. Signup and view all the answers

Which type of pipe is most widely used for drainage systems in buildings under 25 stories?

Cast Iron Pipe Signup and view all the answers

What is a major reason for not using cast iron pipes in buildings taller than 25 stories?

Constant vibrations may cause water leaks at the joints. Signup and view all the answers

Which factor does NOT influence the choice of plumbing pipe materials?

Aesthetics of the pipe Signup and view all the answers

What process causes cast iron pipes to oxidize and form rust?

Reactions with carbon dioxide and other gases Signup and view all the answers

Which of the following materials is NOT commonly used for plumbing installations?

Ceramic Pipe Signup and view all the answers

Why is cost a consideration when choosing plumbing materials?

Lower cost materials may require frequent replacement. Signup and view all the answers

Which type of pipe is known to be affected by corrosion from acid gases?

Cast Iron Pipe Signup and view all the answers

What is one advantage of using cast iron pipes in plumbing?

They are durable and convenient to install. Signup and view all the answers

What is a notable advantage of brass pipe in plumbing installations?

It has a smooth interior and high acid resistance. Signup and view all the answers

Which type of copper pipe is designed specifically for small water supply lines?

M Type Signup and view all the answers

Which copper pipe type is the heaviest and suitable for underground installation?

K Type Signup and view all the answers

What characteristic of stainless steel makes it suitable for drinking water systems?

Resistance to corrosion and high strength. Signup and view all the answers

How do the fittings for copper pipe compare to those for steel pipe?

Copper fittings cost less than those of steel pipe. Signup and view all the answers

What is a unique feature of plastic or synthetic pipes in plumbing?

They are a newer concept in the plumbing field. Signup and view all the answers

Which type of copper pipe is more commonly used for residential water supply?

L Type Signup and view all the answers

What is the main advantage of the smooth interior surface of copper pipe?

It enables the use of a smaller sized pipe without flow reduction. Signup and view all the answers

What does PVC stand for in the context of rigid plastic pipes?

Polyvinyl Chloride Signup and view all the answers

What is the maximum length of Polypropylene Random (PPR) pipes?

30 meters Signup and view all the answers

Which type of plastic pipe is recommended for hot water lines?

Chlorinated Polyvinyl Chloride (CPVC) Signup and view all the answers

Which statement about flexible plastic pipes is true?

Polyethylene (PE) can be flexible and is lighter than steel. Signup and view all the answers

In what year did plastic pipe gain widespread acceptance in the Philippines?

1970 Signup and view all the answers

Which material is not classified as a rigid type of plastic pipe?

Flexible Polyethylene (PE) Signup and view all the answers

What is the primary advantage of plastic pipes over traditional materials?

Greater resistance to rust and corrosion Signup and view all the answers

What characteristic makes Polyethylene (PE) beneficial for construction?

It weighs significantly less than steel. Signup and view all the answers

What is a significant advantage of PVC pipes compared to metal pipes?

They can be lifted by one person. Signup and view all the answers

Which characteristic of PVC pipes helps to maintain optimal flow of water?

Smooth interior surface Signup and view all the answers

Which fitting is NOT commonly associated with Polyvinyl Chloride (PVC)?

Compression Fitting Signup and view all the answers

What is necessary for installing PVC pipe?

Solvent cementing and a saw Signup and view all the answers

What type of fittings can connect PVC pipe to existing metal pipes?

Male and female adaptors Signup and view all the answers

What is the weight comparison of PVC pipe to metal pipe?

PVC weighs about 1/5 of metal pipes. Signup and view all the answers

Which polymer is specifically mentioned for DWV (Drain, Waste, Vent) pipe fittings?

Polyvinyl Chloride (PVC) Signup and view all the answers

Which of the following is NOT a cold water line pipe fitting material mentioned?

Copper Signup and view all the answers

Study Notes

Plumbing Pipes Materials Introduction

Cast iron is a durable and popular material used for drainage systems in buildings but is not preferred for structures over 25 stories due to vibrations.
The choice of pipe material depends on factors like durability, resistance to external and internal contact with foreign matters, resistance to acid waste and chemicals, and cost of materials and labor.

Cast Iron Soil Pipe

Cast iron pipes are prone to corrosion caused by gases like carbon dioxide, sulfur oxide, and methane, which form acids that attack the metal.

Vitrified Clay Pipe

Vitrified clay pipes are impervious to moisture due to high-temperature firing (1370°C), making them highly resistant to acids.
Although durable, clay pipes are brittle and should not be installed on unstable ground.

Lead Pipe

Lead pipes were commonly used for soil and waste pipes in ancient times due to their high acid resistance.
Lead is no longer used for water supply due to its poisonous nature.

Galvanized Steel Pipe

Galvanized steel pipes are made from mild steel and are susceptible to corrosion caused by alkaline and acidic water.
The zinc coating on the pipe can be attacked by carbonic acid, ultimately affecting the steel.
They are prone to deposits of salt and lime, leading to restricted water flow and faster deterioration with hot water supply.

Galvanized Wrought Iron Pipe

Wrought iron pipes are more resistant to acid waste than steel pipes.

Brass Pipe

Brass pipe is an expensive material made from an alloy of zinc (15%) and copper (85%).
Its smooth surface and high acid resistance make it excellent for waste and water supply installations.

Copper Pipe

Copper pipe is durable and extremely corrosion resistant; easy to install.
Compared to steel, copper pipe is slightly more expensive, but its fittings cost less.
Its smooth interior surface allows for smaller size pipes without significant reduction in flow.

Copper Pipe Wall Thickness Types

K type is the heaviest and suitable for underground installations.
L type is lighter than K and available in both rigid and flexible forms, commonly used for residential water supply and radiant heating.
M type is the thinnest and available only in rigid form, designed for small water supply lines and radiant heating.

Stainless Steel Pipe

Stainless steel possesses high strength, resistance to corrosion, heat, and chemical damage, making it suitable for various applications in various environments.
Its chemical composition provides exceptional hygiene guarantees, making it ideal for drinking water systems.

Plastic or Synthetic Pipe

Plastic pipe is a relatively new material in plumbing and has gained popularity for its superiority in sewer and cold water supply lines.

Plastic Pipe Types

Rigid: PVC (polyvinyl chloride), CPVC (chlorinated polyvinyl chloride), uPVC (unplasticized polyvinyl chloride), ABS (acrylonitrile butadiene styrene), PPR (polypropylene random), and SR (styrene rubber plastic).
Flexible: PE (polyethylene), PB (polybutylene).

Plastic Pipe & Hot Water Lines

CPVC, PVDC (polyvinyl dichloride), and PPR are considered suitable for hot water lines but research is ongoing to ensure their long-term durability at high temperatures and pressure.

Advantages of Plastic Pipe

Highly resistant to rust and corrosion.
No pipe taste in the conveyed water.
Smooth interior surface prevents buildup of scale, rust, and debris.
Minimal water turbulence, leading to reduced flow resistance.
Lighter weight than metal pipes (approximately 1/5).
Longer lengths and easy to install with solvent cementing.
PE pipes weigh significantly less than steel pipes.
PVC can be connected to existing metal pipes with threaded adapters.
PVC is virtually acid-proof.
Installation requires minimal tools, only a ruler and saw.
DIY installation is easily possible.

Cold Water Line Pipe Fittings (PVC)

Includes coupling, adopter, plug, cap, elbow (plain, threaded, reducer), tee (plain, threaded, reducer), Teflon tape, union patente, and PVC solvent.

Cold Water Line Pipe Fittings (PPR)

Includes coupling, adopter, plug or cap, elbow (plain, threaded, reducer), tee (plain, male or female threaded, reducer), union patente (plain, male or female threaded), bridge elbow, and fusion machine.

DWV or Storm Line Pipe Fittings (PVC)

Includes elbow (90° and 45°), end cap / clean-out cap, coupling, wye (single or double, equal or reducer), tee (single or double, equal or reducer), long-sweep wye, short-sweep wye, P-trap (with or without plug), and PVC solvent.
