Time Domain Analysis of Control Systems Chapter 5
8 Questions
0 Views

Choose a study mode

Play Quiz
Study Flashcards
Spaced Repetition
Chat to lesson

Podcast

Play an AI-generated podcast conversation about this lesson

Questions and Answers

What is the time response of a control system typically divided into?

  • Two parts: transient response and steady-state response (correct)
  • Four parts: transient response, steady-state response, oscillatory response, and damped response
  • Three parts: transient response, steady-state response, and oscillatory response
  • One part: steady-state response
  • What is the mathematical representation of a ramp function?

  • R*t^2
  • R*e^(-t)
  • R*t (correct)
  • R*u(t)
  • What is the parabolic function in terms of the ramp function?

  • One order slower than the ramp function
  • Two orders slower than the ramp function
  • Two orders faster than the ramp function
  • One order faster than the ramp function (correct)
  • What is the maximum overshoot used to measure in a control system?

    <p>Relative stability</p> Signup and view all the answers

    What is the steady-state error in a control system?

    <p>The difference between the output and the reference in the steady state</p> Signup and view all the answers

    What are the three terms in the denominator that are taken to the limit to determine the steady-state error?

    <p>Static error constants</p> Signup and view all the answers

    How can the steady-state error be found for nonunity feedback systems?

    <p>By using the state space approach</p> Signup and view all the answers

    What is the system type, and the appropriate error constant associated with it, for a unit step input?

    <p>Type 0, position error constant</p> Signup and view all the answers

    Study Notes

    Time Response of Control Systems

    • The time response of a control system is divided into two parts: the transient response and the steady-state response.
    • The time response, y(t), can be written as the sum of the transient response, Yi(t), and the steady-state response, Yss(t).

    Typical Test Signals

    Step-Function Input

    • A step function has a constant magnitude, R.
    • The mathematical representation of a step function is R.

    Ramp Function Input

    • A ramp function changes constantly with time.
    • The mathematical representation of a ramp function is Rt.

    Parabolic-Function Input

    • A parabolic function represents a signal that is one order faster than the ramp function.
    • The mathematical representation of a parabolic function is (R/2)t².

    Steady-State Error

    • The steady-state error is the difference between the output and the reference in the steady state.
    • The steady-state error is determined by the limits of the three terms in the denominator, known as static error constants.
    • The names of the static error constants are:
      • Position error constant (Kp)
      • Velocity error constant (Kv)
      • Acceleration error constant (Ka)

    Evaluating Static Error Constants

    • Example: evaluate the static error constants and find the expected error for standard step, ramp, and parabolic inputs.

    Steady-State Error for Nonunity Feedback Systems

    • Steady-state error can be found from the state space.

    System Type and Steady-State Error

    • The system type, error constant, and steady-state error can be determined for a unit step input.
    • Example: find the system type, the appropriate error constant associated with the system type, and the steady-state error for a unit step input.

    Studying That Suits You

    Use AI to generate personalized quizzes and flashcards to suit your learning preferences.

    Quiz Team

    Related Documents

    Description

    This quiz covers the time response of a control system, including transient and steady-state responses, based on Chapter 5 of Automatic Control System by Kuo.
