What is the maximum allowable height for emergency escape and rescue openings from the floor?

  • 52 inches
  • 44 inches (correct)
  • 38 inches
  • 36 inches
  • What is the minimum horizontal area and width required for a window well?

  • 9 square feet and 36 inches (correct)
  • 12 square feet and 42 inches
  • 6 square feet and 30 inches
  • 15 square feet and 48 inches
  • What is the minimum slope required around a building's perimeter within the first 10 feet?

  • 10 inches
  • 4 inches
  • 6 inches (correct)
  • 8 inches
  • What is the minimum slope required for a composition shingle roof?

    <p>2:12</p> Signup and view all the answers

    What is the temperature drop that house air should experience across the evaporator coil when an air conditioner is operational?

    <p>20 degrees</p> Signup and view all the answers

    What is the acceptable load that intermediate rails or balusters must withstand over a specified area?

    <p>50 pounds on 1 square foot</p> Signup and view all the answers

    What is the main method used in residential frame construction?

    <p>Platform framing</p> Signup and view all the answers

    Which of the following materials is commonly used for gas piping?

    <p>Black iron</p> Signup and view all the answers

    What is the minimum space required between insulation and the roof deck sheathing according to most building codes?

    <p>1 inch</p> Signup and view all the answers

    What is the purpose of a crossover igniter in a gas-fired heating furnace?

    <p>To ignite all burners simultaneously</p> Signup and view all the answers

    What is the minimum interior cross-sectional area required for a shower compartment?

    <p>900 square inches</p> Signup and view all the answers

    What type of barrier is required below any slab intended as a floor for habitable space?

    <p>Vapor barrier</p> Signup and view all the answers

    For a masonry chimney, what is the required height above the roof according to the 3-2-10 rule?

    <p>3 feet above the roof surface</p> Signup and view all the answers

    What is the recommended venting system for a flat roof?

    <p>Passive venting systems</p> Signup and view all the answers

    What type of framing member is a header, and what does it support?

    <p>A horizontal member supporting loads above an opening</p> Signup and view all the answers

    What should be the maximum horizontal spacing for supporting a PVC drainage pipe?

    <p>4 feet</p> Signup and view all the answers

    What does the AFUE rating of 78 to 82% indicate about a mid-efficiency furnace?

    <p>It has a moderate efficiency</p> Signup and view all the answers

    What is the distinguishing characteristic of Type IA ladders?

    <p>Heavy-duty rating of 300 pounds</p> Signup and view all the answers

    What happens when the bottom chord of roofing trusses is exposed to differing moisture or temperature conditions?

    <p>It causes truss uplift</p> Signup and view all the answers

    How often should cleanouts for horizontal drainage pipes be installed?

    <p>Every 100 feet</p> Signup and view all the answers

    What is the purpose of ventilation in relation to roof decks during hot weather?

    <p>To reduce roof deck temperature</p> Signup and view all the answers

    What does the bonding jumper connection do in an electrical system?

    <p>Connects the grounding bus to the electrical enclosure</p> Signup and view all the answers

    Study Notes

    Emergency Escape and Rescue Openings

    • Maximum sill height: No higher than 44 inches above the floor.

    Underlayment for Ice Barrier

    • At least two layers cemented together are needed in ice-prone areas along eaves.

    Window Well Dimensions

    • Horizontal area: At least 9 square feet.
    • Minimum horizontal projection and width: 36 inches.

    Ground Slope Around Building

    • Minimum slope within the first 10 feet of the building perimeter: 6 inches.

    Caulking Materials for Exterior Building Envelope

    • Best performance: Silicone rubber and urethane caulks.

    Basement Vapor Retarders

    • Avoid low permeability vapor retarders (like polyethylene sheets and vinyl wallpaper) on the interior side of basement finishes in some climates. They trap moisture vapor moving through foundation walls.

    Carpet and Wood Floor Application to Slabs on Grade

    • Carpet and wood-based finishes can be applied directly to slabs on grade if the slab or finish surface temperature is raised near room temperature.

    Composition Shingle Roof Slope

    • Minimum slope: 2:12 (2 inches vertical rise for every 12 inches of horizontal run).

    Deck Load Distribution

    • Deck load is carried and distributed by posts and the deck-to-house connection, distributing weight between supporting posts and the attachment point to the house.

    Deck Post Dimensions

    • Minimum dimensions: 6 inches by 6 inches.
    • Maximum height without cross-bracing: 12 feet.
    • Maximum height with cross-bracing: 14 feet.

    Air Conditioner Temperature Drop

    • Temperature drop across evaporator coil: Around 20 degrees.

    Gas Piping Material

    • Common material: Black iron.

    Dew Point

    • Dew point: Temperature at which air must be cooled to reach saturation with water vapor, resulting in condensation.

    Intermediate Rail/Baluster Load Capacity

    • Load capacity: 50 pounds concentrated load on a 1 square foot area.

    Residential Frame Construction

    • Most common method: Platform framing.

    Roof Types

    • Roof without a gable: Hip roof.

    InterNACHI Member Repair Restrictions

    • 12-month restriction on performing repairs on inspected structures.

    Chimney Storm Collar Function

    • Directs rainwater away from the chimney flue onto the flashing to prevent water entry.

    Chimney Height Requirements (3-2-10 Rule)

    • Minimum height: 3 feet above the highest point where the chimney passes through the roof, and 2 feet above any part of the building within 10 feet horizontally.

    Chimney Flue Cross-Sectional Area

    • Determined by fireplace opening area.

    Air Conditioning System Operation Temperature Limit

    • Do not operate below 60 degrees Fahrenheit.

    Dishwasher, Food Grinder, and Kitchen Sink Drainage

    • Can use a common 1 1/2-inch waste drain pipe.

    Flat Roof Venting

    • Recommended venting: Passive venting systems.
    • Common problem: Ponding (water accumulation).

    Sloped Roof Venting

    • Effective venting: Combination of soffit vents (intake) and ridge vent (exhaust).

    Mid-Efficiency Furnace Rating

    • AFUE rating: 78 to 82%.
    • Distinguishing characteristic: Intermittent pilot.

    Plumb Bob Use

    • Creates a vertical reference line, ensuring something is straight.

    Egress Door Dimensions

    • Minimum dimensions: 3 feet wide by 6 feet 8 inches tall.

    Slab Barrier

    • Required barrier below slabs for habitable space: Vapor barrier (6-mil poly or equivalent) or approved moisture barrier.

    Basement Insulation Cover

    • Combustible semi-permeable rigid foam insulation in basements should be covered with a fire-resistant layer (like gypsum) for safety.

    Roof Deck Ventilation in Hot Weather

    • Purpose: Reduces roof deck temperature and improves shingle durability.

    Notches in Lumber Members

    • Maximum notch length in solid lumber joists, rafters, and beams: No longer than one-third the depth of the member.
    • Notches are allowed in the middle third of a floor joist.

    Truss Uplift Cause

    • Truss uplift: Occurs when the bottom chord of roofing trusses is exposed to different moisture or temperature conditions than the rest of the truss.

    Header Function

    • Header: Horizontally placed wooden framing member supporting loads when openings are made in load-bearing walls.

    Shower Compartment Area

    • Minimum interior cross-sectional area: At least 900 square inches.

    Drainage Pipe Cleanout Spacing

    • Maximum spacing: Not more than 100 feet apart.

    PVC Drainage Pipe Support Spacing

    • Maximum horizontal spacing: 4 feet.

    Recessed Ceiling Light Insulation Rating

    • Required rating: IC (Insulation Contact) rated.

    Main Bonding Jumper Connection

    • Purpose: Connects grounding bus to electrical enclosure.

    Electricity and Water Pipe Analogy

    • Voltage: Water pressure.
    • Current: Flow rate.
    • Resistance: Pipe size.

    Grounded Electrical System Conductor Sharing

    • Common bus: Grounded and grounding conductors can share a common bus in a grounded electrical system at the main service panel.

    Service Entrance Conductors

    • Four connected conductors: Indicates a 3-phase supply (three live wires, one neutral/ground).

    Guardrail Design Strength

    • Design strength to resist a 200-pound concentrated load applied at any point along the handrail.

    Insulation and Roof Deck Airflow

    • Minimum space between insulation and roof deck sheathing: 1 inch.

    Gas Furnace Ignition System

    • Crossover igniter: Simultaneously ignites all burners.

    Casement Window Operation

    • Casement window sash: Hinged on one side, swings in or out.

    Three-Coat Stucco System Layers

    • Layers: 3/8-inch scratch coat, 3/8-inch brown coat, and 1/8-inch finish coat.

    Ledger Board Support Restrictions

    • Ledger boards should not be supported by stone, brick veneer, or attached directly to stucco/EIFS (surface-mounted).

    Ladder Duty Rating

    • Type IA ladder duty rating: 300 pounds. Recommended for extra-heavy-duty industrial use.

    Rafter Support

    • After ties and collar ties resist outward thrust and wind suction at the ridge.

    GFCI Receptacle Protection

    • GFCI receptacle protects downstream receptacles, not upstream.
