Analytical Geometry Formulas Overview

Choose a study mode

Play Quiz
Study Flashcards
Spaced Repetition
Chat to Lesson

Podcast

Play an AI-generated podcast conversation about this lesson

Questions and Answers

What is the gradient of a horizontal line?

  • 0 (correct)
  • 1
  • Undefined
  • Negative

Vertical lines have a gradient that is defined.

False (B)

What is the formula to find the distance between two points A(Ax, Ay) and B(Bx, By)?

d = √((Bx - Ax)² + (By - Ay)²)

The equation of a circle centered at the origin is given by __________.

<p>x² + y² = r²</p> Signup and view all the answers

Match the type of line to its gradient:

<p>Horizontal Line = 0 Vertical Line = Undefined Positive Line = m &gt; 0 Negative Line = m &lt; 0</p> Signup and view all the answers

What is the formula to determine the midpoint between points A(Ax, Ay) and B(Bx, By)?

<p>((Ax + Bx)/2, (Ay + By)/2) (B)</p> Signup and view all the answers

Collinear points have equal gradients between them.

<p>True (A)</p> Signup and view all the answers

What does the 'm' represent in the context of lines?

<p>Gradient or slope</p> Signup and view all the answers

What is the radius of the circle with the center at the origin?

<p>7 (C)</p> Signup and view all the answers

The distance between points C(0, 3) and D(2, 19) is longer than 15.

<p>True (A)</p> Signup and view all the answers

What is the midpoint of the diameter CD where C is (0, 3) and D is (2, 19)?

<p>(1, 11)</p> Signup and view all the answers

The equation of a circle in standard form is (x - ______)^2 + (y - ______)^2 = r^2.

<p>h, k</p> Signup and view all the answers

Match the following points with their characteristics:

<p>(2, 0) = x-intercept (0, 3) = y-intercept (1, 1) = neither (5, 0) = x-intercept</p> Signup and view all the answers

If the radius of a circle is 5 and it intersects the x-axis at points (2, 0) and (8, 0), what is the center of the circle?

<p>(5, 0) (B)</p> Signup and view all the answers

Which of the following can be used to find the center and radius of a circle from its equation?

<p>Standard form of a circle equation (D)</p> Signup and view all the answers

A circle can be defined by its center and diameter.

<p>True (A)</p> Signup and view all the answers

What equation represents a circle passing through the point (1, 5) and having its center at (3, 3)?

<p>(x - 3)^2 + (y - 3)^2 = 5</p> Signup and view all the answers

The equation of a circle always requires completing the square to extract its center and radius.

<p>True (A)</p> Signup and view all the answers

What is the key operation used to simplify the equation of a circle?

<p>Completing the square</p> Signup and view all the answers

The center of a circle in the form $(x - a)^2 + (y - b)^2 = r^2$ is located at the point (___, ___).

<p>a, b</p> Signup and view all the answers

Match the following components related to circles with their definitions:

<p>Center = The fixed point at the center of the circle Radius = The distance from the center to any point on the circle Circle Equation = Mathematical representation of a circle Diameter = The length of a line segment that passes through the center and connects two points on the circle</p> Signup and view all the answers

What is the correct formula for the circumference of a circle?

<p>$C = \pi d$ (A), $C = 2\pi r$ (C)</p> Signup and view all the answers

The center of the circle is located at the origin (0,0) if not specified.

<p>False (B)</p> Signup and view all the answers

What does 'sub in' mean in mathematical terms?

<p>Substitute values into an equation</p> Signup and view all the answers

The standard form of the equation of a circle is $(x - ______)^2 + (y - ______)^2 = r^2$.

<p>h, k</p> Signup and view all the answers

Match the following elements with their respective descriptions:

<p>r = Radius of the circle C = Circumference of the circle d = Diameter of the circle (h, k) = Center of the circle</p> Signup and view all the answers

Which of the following points would lie on a circle with a radius of 6 and center (0, 0)?

<p>(0, 6) (B), (6, 0) (D)</p> Signup and view all the answers

The equation $x^2 + y^2 = 49$ describes a circle with a radius of 7.

<p>True (A)</p> Signup and view all the answers

What do you obtain when you complete the square for the equation $x^2 + 11x + y^2 = 36$?

<p>A circle equation in standard form</p> Signup and view all the answers

Flashcards

Gradient

The slope of a line. It represents the steepness of a line and the direction it goes in. It is calculated by dividing the difference in y-coordinates by the difference in x-coordinates of two points on the line.

Point of intersection

The point where two lines intersect. This is the point where both lines share the same x-coordinate and y-coordinate.

Distance between two points

The distance between two points. This is the length of the line connecting the two points.

Diameter

The line that divides a circle into two equal halves. It passes through the center of the circle.

Signup and view all the flashcards

Radius

The line from the center of a circle to any point on the circle's edge.

Signup and view all the flashcards

Midpoint

The point that divides a line segment into two equal parts. The mid-point lies exactly halfway between the two endpoints.

Signup and view all the flashcards

Trapezium

A shape with four sides, where one pair of opposite sides are parallel and equal in length, while the other pair of opposite sides are also parallel but not necessarily equal.

Signup and view all the flashcards

Diagonal

A line segment connecting two opposite vertices of a trapezium.

Signup and view all the flashcards

Substitution in equations

A process of substituting known values into a formula to solve for an unknown variable.

Signup and view all the flashcards

Solving equations

A method of solving equations that involves performing operations on both sides of the equation to isolate the unknown variable.

Signup and view all the flashcards

Equation of a circle

A method of finding the equation of a circle when given its center and radius.

Signup and view all the flashcards

Simplifying expressions

The process of manipulating an expression to simplify it or to make it easier to solve.

Signup and view all the flashcards

Expanding and simplifying

A technique used to rewrite expressions by multiplying out brackets and combining like terms.

Signup and view all the flashcards

Y-intercept

The point where a graph crosses the y-axis.

Signup and view all the flashcards

Inverse operations

A method for solving equations that involves isolating the unknown variable by performing inverse operations on both sides of the equation.

Signup and view all the flashcards

Finding the equation of a circle

A method of finding the equation of a circle when given certain points on the circle and its center.

Signup and view all the flashcards

Completing the Square (CTS)

A method used to rewrite an equation in the form (x-a)² + (y-b)² = r² to identify the centre (a, b) and radius (r) of a circle.

Signup and view all the flashcards

Centre of a Circle: x-coordinate

In the form (x-a)² + (y-b)² = r², 'a' represents the x-coordinate of the centre of the circle.

Signup and view all the flashcards

Centre of a Circle: y-coordinate

In the form (x-a)² + (y-b)² = r², 'b' represents the y-coordinate of the centre of the circle.

Signup and view all the flashcards

Radius of a Circle

In the form (x-a)² + (y-b)² = r², 'r' represents the radius of the circle.

Signup and view all the flashcards

Center of a Circle from Diameter

To find the center of a circle given its diameter, find the midpoint of the diameter. The midpoint will be the center of the circle.

Signup and view all the flashcards

Finding the Equation of a Circle with x-intercepts

When finding the equation of a circle given x-intercepts, remember that the x-intercepts are points on the circle. These points can be used to find the radius or other information needed to complete the equation.

Signup and view all the flashcards

Finding the Equation of a Circle through Two Points

To find the equation of a circle passing through two given points, substitute the coordinates of both points into the standard equation of a circle. This will give you two equations with two unknowns (h and k, the center of the circle). Solve for h and k.

Signup and view all the flashcards

Radius in Circle Equation

When finding the equation of a circle, the radius (r) is a key component. Use the distance formula to find the radius if you know the center point and a point on the circle.

Signup and view all the flashcards

Equation of a Circle: Summary

To find the equation of a circle when given key information like the center, radius, or points on the circle, use the standard equation of a circle: (x - h)^2 + (y - k)^2 = r^2. Substitute values and solve for missing components.

Signup and view all the flashcards

Study Notes

Analytical Geometry Formulas

  • Straight Lines:
    • y = mx + c (where c is the y-intercept)
    • y - y₁ = m(x - x₁) (where (x₁, y₁) is a point on the line)
  • Point of Intersection: Use simultaneous equations.
  • Horizontal Line: y = c
  • Vertical Line: x = k
  • Distance Formula: AB = √((x₂ - x₁)² + (y₂ - y₁)²) (calculates distance between points A(x₁, y₁) and B(x₂, y₂))
  • Gradient (m): m = (y₂ - y₁) / (x₂ - x₁) (for points A(x₁, y₁) and B(x₂, y₂))
    • The gradient of a horizontal line is 0.
    • The gradient of a vertical line is undefined.

Angle of Inclination

  • To determine the angle of inclination, use: m = tan θ (θ is the angle of inclination)
  • Four things to remember about gradient: -If two lines are parallel, their gradients are equal (m₁=m₂). -If two lines are perpendicular, the product of their gradients is -1 (m₁ x m₂= -1). -Points are collinear if the gradient between any two points is the same. -Gradient is the tangent of the angle of inclination.

Midpoint Formula

  • The midpoint between points A(x₁, y₁) and B(x₂, y₂) is given by M = ((x₁ + x₂)/2, (y₁ + y₂)/2).
