Mechanical Engineering: Introduction to Thermodynamics
40 Questions
0 Views

Choose a study mode

Play Quiz
Study Flashcards
Spaced Repetition
Chat to lesson

Podcast

Play an AI-generated podcast conversation about this lesson

Questions and Answers

What is the characteristic feature of a quasi-static process?

  • High pressure
  • Infinite slowness (correct)
  • Finite slowness
  • Fast reaction rate

    • Which of the following is an example of a reversible process?

  • Frictional adiabatic expansion of a fluid
  • Frictionless isothermal expansion of a fluid (correct)
  • Frictional isothermal expansion of a fluid
  • Frictional compression of a fluid

    • What is the result of an irreversible process?

  • No change in the Universe
  • Net change in the Universe (correct)
  • No effect on the surrounding
  • Reversible process

    • What is the formula for calculating work done?

    <p>W=F·d·cos(?)</p> Signup and view all the answers

    What is pressure-volume work commonly known as?

    <p>PV work</p> Signup and view all the answers

    What is the sign convention for work done by the system on the surroundings?

    <p>Positive</p> Signup and view all the answers

    What is the relation between internal energy, heat, and work?

    <p>?U=Q-W</p> Signup and view all the answers

    What is chemical equilibrium related to?

    <p>Chemical potential</p> Signup and view all the answers

    What is the definition of thermodynamic work?

    <p>Work involves energy transfer that occurs when a system undergoes a change in volume or pressure</p> Signup and view all the answers

    What is the unit of work in the International System of Units (SI)?

    <p>Joule (J)</p> Signup and view all the answers

    What is the primary focus of thermodynamics?

    <p>Energy and its transformation</p> Signup and view all the answers

    What is the term for the quantity of matter or a region in space chosen for study?

    <p>Thermodynamic system</p> Signup and view all the answers

    In a closed system, what can cross the boundary?

    <p>Energy in the form of heat or work</p> Signup and view all the answers

    What is the term for the boundary of a control volume?

    <p>Control surface</p> Signup and view all the answers

    Which approach considers the events occurring at the molecular level?

    <p>Microscopic approach</p> Signup and view all the answers

    What is the primary focus of the macroscopic approach?

    <p>Overall behavior of the system</p> Signup and view all the answers

    What is the benefit of the macroscopic approach?

    <p>Requires simple mathematical formulae</p> Signup and view all the answers

    What is an example of an open system?

    <p>Both A and B</p> Signup and view all the answers

    What is a characteristic of a closed system?

    <p>Fixed amount of mass</p> Signup and view all the answers

    What is the term for the real or imaginary surface that separates the system from the surrounding?

    <p>Boundary</p> Signup and view all the answers

    What is a quasi-equilibrium process?

    <p>A process that remains infinitesimally close to an equilibrium state at all times</p> Signup and view all the answers

    What is a point function?

    <p>A quantity that is independent of the path</p> Signup and view all the answers

    What is a path function?

    <p>A quantity that depends on the path</p> Signup and view all the answers

    What is a cycle in thermodynamics?

    <p>A process that returns to its initial state at the end of the process</p> Signup and view all the answers

    What is temperature?

    <p>A measure of degree of hotness or coldness</p> Signup and view all the answers

    What is the relation between Kelvin and Celsius scales?

    <p>T(K) = T(C) + 273.16</p> Signup and view all the answers

    What is pressure?

    <p>Force per unit area</p> Signup and view all the answers

    What is the unit of pressure in the SI system?

    <p>Pa</p> Signup and view all the answers

    What is thermodynamic equilibrium?

    <p>A state where no changes in macroscopic property are observed if the system is isolated</p> Signup and view all the answers

    What is mechanical equilibrium?

    <p>Equality of pressure</p> Signup and view all the answers

    What is the main characteristic of the microscopic approach?

    <p>Studying the motion of molecules and their interactions</p> Signup and view all the answers

    What is an intensive property of a system?

    <p>A property that is independent of the size of the system</p> Signup and view all the answers

    What is the specific volume of a substance?

    <p>The volume of the substance per unit mass</p> Signup and view all the answers

    What is the state of a system described by?

    <p>Its properties and their values</p> Signup and view all the answers

    What is a process in thermodynamics?

    <p>A change in the state of a system</p> Signup and view all the answers

    What is the characteristic of a system in thermal equilibrium?

    <p>The temperature is same throughout the system</p> Signup and view all the answers

    What is the continuum idealization?

    <p>A continuous, homogeneous matter with no holes</p> Signup and view all the answers

    What is an extensive property of a system?

    <p>A property that depends on the size of the system</p> Signup and view all the answers

    What is the specific gravity of a substance?

    <p>The ratio of its density to the density of a standard substance</p> Signup and view all the answers

    What is equilibrium in thermodynamics?

    <p>A state of balance in the system</p> Signup and view all the answers

    Study Notes

    Introduction to Thermodynamics

    • Thermodynamics is the science of energy and its transformations, dealing with equilibrium and feasibility of processes.
    • It involves the relationship between heat and work, and the properties of systems in equilibrium.

    Thermodynamic System

    • A thermodynamic system is a quantity of matter or a region in space chosen for study.
    • The system is separated from the surrounding by a boundary, which can be real or imaginary.
    • The system can be classified into two types: closed system and open system.

    Closed System (Control Mass)

    • A closed system consists of a fixed amount of mass, and no mass can cross its boundary.
    • Energy in the form of heat or work can cross the boundary, but the volume of the system does not have to be fixed.
    • Example: piston-cylinder device.

    Open System (Control Volume)

    • An open system is a properly selected region in space, and both mass and energy can cross its boundary.
    • The boundary of a control volume is called a control surface, which can be real or imaginary.
    • Example: compressor, turbine, nozzle.

    Macroscopic and Microscopic Approaches

    • The macroscopic approach considers a system as a whole, without taking into account events at the molecular level.
    • The microscopic approach considers the system as comprising of many tiny particles, with molecular motion and random interactions.
    • The macroscopic approach is used in classical thermodynamics, while the microscopic approach is used in statistical thermodynamics.

    Properties of a System

    • A property is a characteristic of a system, which can be independent or dependent.
    • Intensive properties are independent of the size of the system, such as temperature, pressure, and density.
    • Extensive properties depend on the size of the system, such as mass, volume, and total energy.
    • Specific properties are extensive properties per unit mass, such as specific volume, specific energy, and specific gravity.

    State and Equilibrium

    • The state of a system is described by its properties, and a system is in equilibrium when there are no unbalanced potentials or driving forces within the system.
    • A system is in thermal equilibrium when the temperature is uniform throughout the system, and in mechanical equilibrium when there is no change in pressure at any point of the system.
    • A system is in chemical equilibrium when its chemical composition does not change with time.

    Processes and Quasi-Equilibrium

    • A process is a change that a system undergoes from one equilibrium state to another.
    • A quasi-equilibrium process is an idealized process that proceeds in such a way that the system remains infinitesimally close to an equilibrium state at all times.
    • Quasi-equilibrium processes are easy to analyze and are used as standards to compare actual processes.

    Point Function and Path Function

    • A point function is a quantity whose change is independent of the path, such as properties like pressure, volume, and temperature.
    • A path function is a quantity whose value depends on the path followed during a change of state, such as heat and work.

    Cycle and Steady Flow Process

    • A cycle is a process in which the system returns to its initial state at the end of the process.
    • A steady flow process is a process in which a fluid flows through a control volume steadily.

    Temperature and Pressure

    • Temperature is a measure of hotness or coldness, and it is a point function.
    • Pressure is defined as the force exerted by a fluid per unit area, and it is a point function.

    Thermodynamic Equilibrium

    • A system is in thermodynamic equilibrium when no changes in macroscopic properties are observed when it is isolated from its surroundings.
    • The conditions for thermodynamic equilibrium are thermal equilibrium, mechanical equilibrium, and chemical equilibrium.

    Quasi-Static and Reversible Processes

    • A quasi-static process is a process that is performed in such a way that the deviation from thermodynamic equilibrium is infinitesimal.
    • A reversible process is a process that can be executed in either direction, with no dissipative effects such as friction or loss of energy.

    Irreversible Process

    • An irreversible process is a process that cannot be restored to its initial state, and the system and surroundings are affected by loss of work and gain of low-temperature heat.

    Work and Heat Transfer

    • Work is the transfer of energy that occurs when a force is applied to an object, causing it to move.
    • Thermodynamic work involves energy transfer that occurs when a system undergoes a change in volume or pressure.
    • Pressure-volume work is the most common type of thermodynamic work, and it is given by W = PΔV.
    • Sign convention for work transfer: work done by the system is positive, and work done on the system is negative.
