Questions and Answers

What is the role of the rotor in a DC machine?

It forms a protective covering over the inner parts.

It houses the field winding.

It generates the magnetic poles.

It rotates in the magnetic field. (correct)

Which component is essential for the magnetic field in a DC machine?

Field winding (correct)

Armature winding

Brushes

Commutator

What is the main purpose of the yoke in a DC machine?

To connect the brushes.

To rotate in the magnetic field.

To assist in generating electrical energy.

To provide protection and carry magnetic flux. (correct)

How are the magnetic poles in a DC machine constructed?

With a pole core and pole shoe under hydraulic pressure. (B) Signup and view all the answers

What distinguishes a DC motor from a DC generator?

The direction of energy conversion. (D) Signup and view all the answers

Which part of the DC machine directly interacts with electrical energy?

Commutator (B) Signup and view all the answers

What material is typically used for field coils in a DC machine?

Copper wire (C) Signup and view all the answers

What is the function of brushes in a DC machine?

To connect the winding to the power supply. (D) Signup and view all the answers

What is the main function of the commutator in a DC machine?

To collect current from armature conductors (A) Signup and view all the answers

Which material is commonly used to make brushes in a DC machine?

Carbon or graphite (C) Signup and view all the answers

What is the role of bearings in a DC machine?

To support the machine shaft with minimum friction (D) Signup and view all the answers

How are the armature coils arranged in wave winding?

Divided into two parallel paths overall (A) Signup and view all the answers

In lap winding, how many parallel paths does the armature winding have?

As many as the number of poles (B) Signup and view all the answers

What component collects the current from the commutator to supply the stationary circuit?

Brushes (D) Signup and view all the answers

Which of the following statements about the structure of the commutator is correct?

It has copper segments insulated by mica. (C) Signup and view all the answers

What is a key benefit of using bearings in DC machines?

Reduction of frictional losses (C) Signup and view all the answers

Study Notes

DC Machines Construction

A DC machine is an electromechanical device that converts direct current (DC) electrical energy to mechanical energy or vice versa.
If the device converts DC electrical energy to mechanical energy, it's a DC motor.
If it converts mechanical energy to DC electrical energy, it's a DC generator.
Both motors and generators have similar construction.

Main Parts

Two major parts are needed:
- Stator: Houses the field winding.
- Rotor: The rotating part that turns in a magnetic field.

Other Parts

Yoke (or Frame): A protective covering around the inner parts of the motor. It also carries the magnetic flux created by the poles.
Poles and Pole Shoes: Magnetic structures fitted onto the yoke. They have a core and a shoe. The poles and the core are placed together, with pressure.
Field Winding: Made from copper coils, they're wound around the pole shoes
Armature: The armature core has slots where the armature windings (copper wire) reside. The windings are distributed uniformly.
Commutator: A cylindrical structure made of copper segments. Each is insulated by mica to prevent short circuits, allowing current collection from armature conductors.
Brushes: Carbon or graphite structures that make contact with the commutator; collecting current from the commutator and passing it to the stationary circuit.
Bearings: Support the rotor shaft. Reducing friction losses in the machine.

Types of Armature Winding

Wave Winding: Armature coils are connected in series through the commutator segments. The armature winding is divided into two parallel paths, regardless of the number of poles.
Lap Winding: Armature coils connect in series to the commutator segments, causing a division of the winding into multiple parallel paths, equivalent to the number of poles in the machine.

Studying That Suits You

Use AI to generate personalized quizzes and flashcards to suit your learning preferences.

Description

Test your knowledge on the construction of DC machines, including the essential components of DC motors and generators. This quiz covers the major parts like the stator, rotor, and other vital components. Get ready to explore the fundamental concepts of electromechanical devices.
