Database Systems: ER Diagrams and Relationships
18 Questions
52 Views

Choose a study mode

Play Quiz
Study Flashcards
Spaced Repetition
Chat to Lesson

Podcast

Play an AI-generated podcast conversation about this lesson

Questions and Answers

What is the primary characteristic of a weak entity in entity-relationship modeling?

  • It has multiple attributes with high cardinality
  • It has a unique identifier
  • It participates in an identifying relationship with an owner entity (correct)
  • It has a recursive relationship with itself

What type of relationship exists between an entity and itself in entity-relationship modeling?

  • Unary relationship (correct)
  • N-ary relationship
  • Ternary relationship
  • Binary relationship

What is the term for the number of entities participating in a relationship in entity-relationship modeling?

  • Strength
  • Constraint
  • Degree (correct)
  • Cardinality

What is the relationship type that exists between three different entities in entity-relationship modeling?

<p>Ternary relationship (D)</p> Signup and view all the answers

What is the primary purpose of an identifying relationship in entity-relationship modeling?

<p>To identify a weak entity (D)</p> Signup and view all the answers

What is the term for the direction of operation in entity-relationship modeling?

<p>Bidirectional (B)</p> Signup and view all the answers

What is a characteristic of a weak entity?

<p>Its existence depends on another entity. (D)</p> Signup and view all the answers

What type of entity is used to implement M:N relationships between entities?

<p>Associative entity (D)</p> Signup and view all the answers

What is the purpose of an associative entity?

<p>To connect multiple entities in a M:N relationship (D)</p> Signup and view all the answers

What is a characteristic of a generalization entity?

<p>It encapsulates common characteristics of many entities (A)</p> Signup and view all the answers

What is an aggregation entity composed of?

<p>A set of entities (B)</p> Signup and view all the answers

What is the relationship between a class and a set of member classes in a generalization entity?

<p>Set-subset relationship (C)</p> Signup and view all the answers

What is the main difference between a stored attribute and a derived attribute?

<p>Derived attributes are calculated from other attributes, while stored attributes are manually entered by the user. (B)</p> Signup and view all the answers

In Chen notation, how is an attribute typically represented?

<p>As an oval containing its name and connected to the entity with a line. (D)</p> Signup and view all the answers

What is the main characteristic of a weak entity in entity-relationship modeling?

<p>It has a partial key and depends on another entity for its existence. (B)</p> Signup and view all the answers

What should be done when implementing a multivalued attribute in a relational database?

<p>Create a new entity for each of the original multivalued attributes’ components. (C)</p> Signup and view all the answers

What is the purpose of a partial key in a weak entity?

<p>To identify a unique instance of the weak entity. (C)</p> Signup and view all the answers

What is the main difference between a regular entity and a weak entity?

<p>A regular entity exists independently of other entities, while a weak entity exists only in relation to another entity. (B)</p> Signup and view all the answers

Flashcards

Single-valued Attribute

An attribute that can have only a single value. For example, a person's gender or a product's price.

Multivalued Attribute

An attribute that can have multiple values. For example, a student's list of courses or a product's list of features.

Stored Attribute

An attribute that must be provided by the user and stored in the database. For example, a customer's name or a product's description.

Derived Attribute

An attribute that is calculated from other attributes and doesn't need to be stored. For example, a customer's total purchase amount calculated from the quantity and price of items.

Signup and view all the flashcards

Attribute Representation in ERD

A representation of an entity in an ERD. It is commonly used in the Chen notation and shows the name of the attribute in an oval.

Signup and view all the flashcards

Regular Entity

An entity that exists independently of other entities. It has a primary key and is considered the main building block of the database.

Signup and view all the flashcards

Weak Entity

An entity that depends on another entity for its existence. It doesn't have its own primary key but may have a partial key.

Signup and view all the flashcards

Associative Entity

An entity that represents the association between two or more other entities. It is used to implement Many-to-Many relationships.

Signup and view all the flashcards

Unary Relationship

A relationship type that involves only one entity. For example, an employee reporting to their manager, which is also an employee.

Signup and view all the flashcards

Binary Relationship

A relationship type that involves two different entities. For example, a student taking a course.

Signup and view all the flashcards

Ternary Relationship

A relationship type that involves three different entities. For example, an employee working on a project for a department.

Signup and view all the flashcards

Identifying Relationship

A relationship between entities where the existence of the weak entity depends on the identifying entity.

Signup and view all the flashcards

Partial Key

A key attribute that is used to identify a weak entity. It is composed of the primary key of the identifying entity and any additional attributes needed to uniquely identify the weak entity.

Signup and view all the flashcards

Bidirectional Relationship

A relationship between entities that operates in both directions. For example, a student taking a course also means the course has a student enrolled.

Signup and view all the flashcards

Relationship Cardinality

A relationship between entities that is expressed with a degree of involvement between the entities. This can indicate a relationship of one-to-one, one-to-many, or many-to-many.

Signup and view all the flashcards

Relationship Constraint

A type of relationship that shows how many instances of one entity can be related to another. For example, a one-to-one relationship means one instance of an entity is related to one instance of another entity. This type of relationship will have a maximum number of instances of each entity within the relationship.

Signup and view all the flashcards

Study Notes

Attributes

  • Single-value attributes can have only a single value.
  • Multivalued attributes can have many values.
  • Stored attributes must be entered by the user and stored in the database.
  • Derived attributes are calculated from other attributes and are not required to be stored in the database.
  • M:N relationships and multivalued attributes should not be implemented in relational tables.
  • Create several new attributes for each of the original multivalued attributes' components.
  • Create a new entity composed of original multivalued attributes' components.

Attributes Representation in ERD

  • Chen notation: attributes are represented by an oval containing its name and connected to the entity with a line.
  • Crow's Foot notation: attributes are written in an attribute box below the entity rectangle.

Types of Entities

Regular/Strong Entities

  • Existence does not depend on any other entity.
  • Has a key attribute.
  • Examples: Employees, Departments, Projects, and Students entities.

Weak/Subordinate Entities

  • Existence depends on another entity.
  • Has no key attributes of its own, but may have a Partial key.
  • Weak entities are identified by the combination of their Partial key (if exists) and Primary key of its identifying entity.
  • Examples: Dependent and Invoice entities.

Associative/Composite/Bridge Entities

  • Existence depends on two or more entities.
  • Used to implement M:N relationship between entities.
  • Composed of all key attributes of all connected entities.
  • May contain additional attributes that play no role in the connective process.
  • Has no key attributes of its own, but may have a Partial key.
  • Associative entities are identified by the combination of their Partial key (if exists) and all Primary keys of their identifying entities.
  • Examples: student grades depend on the student and the course.

Generalization

  • Encapsulates common characteristics of many subordinate entities.
  • Defines a set-subset relationship between a class and a set of member classes.
  • Used with Enhanced Entity Relationship Diagram (EER/E2R).
  • Examples: a four-wheeler is a type of vehicle, and a truck is a type of four-wheeler.

Aggregation

  • Consists of or an aggregation of other entities.
  • Defines a new entity from a set of entities which are identified as components of the root entity.
  • Used with Enhanced Entity Relationship Diagram (EER/E2R).
  • Examples: a car consists of engine, chassis, gear box, etc.

Relationships

  • Association between entities.
  • Participants are entities that participate in a relationship.
  • Relationships between entities always operate in both directions.
  • More than one relationship type can exist with the same participating entity types.
  • The relationship type has three main characteristics: Degree, Strength, and Cardinality/Constraints.
  • A weak entity must participate in an identifying relationship type with an owner or identifying entity type.

Relationships Degree

  • Unary/Recursive: Relationship between an entity and itself.
  • Binary: Relationship between two different entities.
  • Ternary: Relationship between three different entities.
  • Nary: Relationship between N different entities.
