Alternating Current Concepts
18 Questions
4 Views

Choose a study mode

Play Quiz
Study Flashcards
Spaced Repetition
Chat to lesson

Podcast

Play an AI-generated podcast conversation about this lesson

Questions and Answers

What happens to the period time of a sine wave as rpm increases?

  • It fluctuates
  • It is increased
  • It remains constant
  • It is reduced (correct)
  • How many cycles does a four-pole generator complete per revolution?

  • Four
  • Three
  • One
  • Two (correct)
  • When does the peak value of a sine wave occur?

  • At the end of the cycle
  • Twice each cycle (correct)
  • Constantly throughout the cycle
  • At the start of the cycle
  • What is the peak-to-peak value of a sine wave?

    <p>The magnitude between peak positive and peak negative values</p> Signup and view all the answers

    Which of the following best defines instantaneous voltage or current?

    <p>The value at any time on the sine wave</p> Signup and view all the answers

    How does an increase in poles affect the number of cycles completed in a revolution by a generator?

    <p>Increases the number of cycles</p> Signup and view all the answers

    In a three-phase AC generator, what is the phase difference between the three conductors?

    <p>120°</p> Signup and view all the answers

    If two sine waves are out of phase, what does it mean?

    <p>They do not reach their maximum and minimum points at the same time</p> Signup and view all the answers

    Which of the following is NOT a type of AC signal waveform mentioned in the text?

    <p>Gaussian wave</p> Signup and view all the answers

    What is a distinguishing feature of alternating waves, according to the text?

    <p>Equal areas are enclosed above and below the time axis</p> Signup and view all the answers

    In the context of AC signals, what does the term 'waveform' refer to?

    <p>The shape of the signal over time</p> Signup and view all the answers

    Which of the following statements about AC voltage levels is true, based on the information in the text?

    <p>They alternate between positive and negative values</p> Signup and view all the answers

    What determines the direction of current movement in an alternating current (AC) circuit?

    <p>The generated terminal voltage polarities</p> Signup and view all the answers

    What is the relationship between the amplitude of the positive and negative alternations in an AC waveform?

    <p>The amplitude of the positive alternation and the amplitude of the negative alternation are the same</p> Signup and view all the answers

    What is the relationship between the current in an AC circuit and the current in a DC circuit?

    <p>AC current is a function of time, while DC current is constant</p> Signup and view all the answers

    What is the most common waveform used to represent AC?

    <p>Sinusoidal wave</p> Signup and view all the answers

    What is the relationship between the speed of a conductor cutting through a magnetic field and the induced EMF?

    <p>The faster the conductor cuts through the magnetic field, the greater the induced EMF</p> Signup and view all the answers

    What is the purpose of a filter in an electrical circuit?

    <p>To remove unwanted frequency components from the signal</p> Signup and view all the answers

    Study Notes

    Sine Waves and AC Power

    • The period of a sine wave is the time taken for one cycle, and it decreases as the rotational speed (rpm) increases.
    • The number of poles in a generator affects the number of cycles completed in a revolution (e.g., two-pole generator completes one cycle per revolution, four-pole generator completes two cycles per revolution).
    • Peak voltage or current occurs twice in each cycle, at the positive and negative maximum values.
    • Peak-to-peak voltage or current is the magnitude of the voltage or current between the peak positive and peak negative values.
    • Instantaneous voltage or current is the value at any time on the sine wave, ranging from zero to peak value.

    Phase and Sine Waves

    • Sine waves can be in-phase or out of phase, depending on whether they reach their maximum and minimum points at the same instant of time.
    • When sine waves are out of phase, a phase difference exists between them, meaning they do not reach their maximum and minimum points simultaneously.

    Three-Phase AC Power

    • A three-phase (3Ø) generator has three conductors, producing three phases of AC power that are 120° apart.
    • Three-phase AC power is used in many applications.

    AC Signal Types

    • AC signals include sine waves, square waves, triangular waves, and sawtooth waves, among others.
    • AC voltage levels change with time, alternating between positive and negative values.
    • The distinguishing feature of alternating waves is that equal areas are enclosed above and below the time-axis.
    • The amplitude of the positive and negative alternations are the same.

    Simple AC Generator

    • A simple AC generator consists of a coil rotated through a uniform magnetic field at a constant speed.
    • The sinusoidal sine wave represents the induced EMF at each instant of time during 360° rotation of the loop.
    • AC, unlike DC, flows first in one direction and then in the opposite direction.
    • The current amperage is a function of time, unlike DC amperage which is constant.
